| POWER | 96W |
| INPUT VOLTAGE | 100-130V |
| OUTPUT VOLTAGE | 24V |
| OUTPUT CURRENT | 4A |
| PF | >0.99 |
| EFFICIENCY | 90%-92% |
| PRODUCT SIZE (mm) | 105*54*51mm |
| Location | for indoor Dry, Damp |
| CERTIFICATION | UL Class 2 Class P FCC |
DD-24096-DIM
DD-24096-DIM
$0.00
The DD Series combines a driver and dimmer into one sleek, elegant designer-style wall switch, simplifying installation and saving space. It features a large paddle switch with a small dimming slider, fits standard wall plates, and is perfect for remodeling projects where hiding an LED driver is difficult or impossible. With soft dimming down to 0.1%, wide compatibility, and no minimum load required, it’s the smarter, all-in-one choice for your next lighting project.
- Output: Constant Voltage
- Input Range: 120VAC
- PFC design: Built-in active PFC function
- Protections: Short circuit/ Over load/ Over temperature
- Heat dissipation: Cooling by free air convection
- Waterproof performance: For dry and damp locations (US)
- Design features:
- 1)Fine-tune output voltage can be adjusted slightly
- 2)Preset dimmer with on/off switch
- 3)3-Way switches
- 4)Eliminated compatibility issues between drivers and switches
- Dimming range: 0.3%-100%
- Application: Suitable for the application of LED lighting
- Warranty: 5 years warranty
- Others: 16KHZ PWM output with dimming curve is a gamma 2.2 curve Flicker-free
